Material |
Chrome-plated Brass |
---|---|
Spray Type |
None |
Installation Type |
Deck Mount |
Features |
Solid Brass Waterway Construction Vandal-resistant Aerator with Key |
Dimensions |
L: 9-3/4" W: 6-5/8" H: 6-5/8" |
Handle Quantity |
2 |
Handle Type |
Push Button |
Deck Clearance |
1-3/4" |
Spout Reach |
5" |
Spout Height |
2-3/8" |
Hole Drillings |
3 |
Application Type |
Lavatory |
Spout Type |
Fixed Spout |
Valve Type |
Ceramic Disc |
Valve Connection |
1/2"-14 NPSM |
Shipping Dimensions |
L: 16" W: 10" H: 6" |
Shipping Weight |
6 LBS |
Country Of Origin |
USA |
ADA |
Yes |
Code Compliance Faucets |
ADA & ICC A117.1 ASME A112.18.1/CSA B125.1 CEC NSF 372 (lead free) NSF 61 |
Note |
Cycle time: 2-25 seconds across a 20-80 PSI pressure range (0.35 - 2.2 GPM flow rate). Factory setting: 8-12 seconds at 60 PSI. |
Elkay® commercial faucets combine performance and style. From the commercial kitchen to the classroom, we have faucets for a variety of applications. Select from options and styles that make it easier to take on the tasks you do every day.
